Writing a Programmers Editor (DS/Gapbuffer) - Part 2

In my quest to write a programmable editor the first problem that i came across was which datastructure to hold the text in? What do other text editors use? For instance emacs in which this blog is written uses a gap buffer. Gap buffer is a linear array with two extra empty spaces in the array. Let me demonstrate how a gap buffer looks like.

Notice the green boxes in the diagram above. Those represent the gap — empty space in the array reserved for future insertions. The text "HELLO WORLD" sits in a single contiguous array, but the gap splits it into two segments: the text before the cursor and the text after the cursor.

When you move the cursor one position to the right (from before "H" to after "H"), the gap shifts with it. The "H" jumps from the right side of the gap to the left side. This is the fundamental mechanic of a gap buffer.

Why is this clever?

Because insertion and deletion at the cursor position becomes essentially free. When you type a character, it fills the empty gap space — no shifting of text required. When you press backspace, the gap simply grows by one. The cursor is always inside the gap, and edits happen at gap boundaries.

Notice how each typed character occupies one green box, reducing the gap size by one. The gap shrinks from the left edge, meaning the new characters appear before the cursor. This is why insertion is O(1) — it is just a memory write at the gap boundary. No existing text needs to be shifted.

• Insertion: O(1) — write into gap, shrink gap by one.
• Deletion: O(1) — expand gap by one, no data movement.
• Cursor movement: O(n) worst case — gap must travel, shifting characters across.

But wait, isn't cursor movement expensive?

In practice, no. Most cursor movements are short hops — a few characters left or right, up or down a line. The gap only shifts by a few positions. The worst case (Ctrl+End jumping to the end of a large file) does incur a cost, but it is a single memmove — a blazingly fast operation on modern hardware.

When moving the cursor right, characters on the left side of the gap are "peeled off" the right segment and appended to the left segment. A move of N positions requires shifting N characters across the gap boundary — hence O(N). For small N this is negligible; the memmove call completes in nanoseconds.

The real question is: what happens when the gap runs out of space?

When you keep typing and the gap fills up completely, the buffer must be resized. This involves allocating a larger array and copying the contents over — an O(n) operation. Emacs handles this by doubling the buffer size, giving you ample gap space before the next resize. The amortized cost per insertion remains O(1).

This is the only O(N) operation in the gap buffer's repertoire. But because the buffer size doubles each time — 8 → 16 → 32 → 64 — the resizes become progressively rarer. Type a single character and you get a fresh gap of 8 empty slots. Type 1000 characters and you get a gap of 1024. The cost amortizes to zero over the lifetime of the buffer.

What about other data structures?

The gap buffer is not the only option. Several alternatives exist, each with their own trade-offs:

• Rope: A binary tree where each leaf holds a short string fragment. Insertion and deletion are O(log n). Excellent for very large documents. Used by Xi-editor and Zed.
• Piece Table: A table of pieces — references into an original buffer and an append-only change buffer. Never modifies the original. Used by VS Code and Microsoft Word.
• Linked List of Lines: Each line is a separate string node. Simple but slow for cross-line operations. Used by many naive editors and early versions of notepad.
• Array (Flat): A single contiguous array with no gap. Every insertion requires O(n) shifting. Simple but impractical for real-time editing.

So why does emacs stick with the gap buffer? Because for the vast majority of editing scenarios — typing, deleting, small cursor movements — the gap buffer is hard to beat. It has excellent cache locality (everything is in one contiguous array), minimal allocation overhead, and is trivially simple to implement.

Which one should we pick for our editor?

Remember from the Part 1 — the goal is to write an editor in a lisp or scheme that gives 100% power to the user. A gap buffer is simple enough to implement in scheme in an afternoon, and its performance characteristics are well understood. A rope or piece table would add complexity that may not pay off until the editor handles very large files.

There is also a philosophical angle. The gap buffer embodies a principle that resonates with lisp: simple primitives that compose well. A gap buffer is just an array with a split point. You can build higher-level abstractions — undo history, multi-cursor, collaborative editing — on top of it without fighting the data structure.

But does simple mean good enough?

That is the question we will explore in the next part. We will implement a gap buffer in scheme, wire it up to a basic display routine, and measure its performance on real-world editing workloads. The question is not just can we build an editor on a gap buffer? — emacs already proved that. The question is can we build one that is entirely in scheme, with no C runtime, and still feel fast?

Watchout for the next part of the assay, till then.

Shorel'aran
